OCULUSâ„¢

The OCULUS gauge records pressure and temperature precisely, it is rugged and able to transmit high resolution data for DST operations and production wells.

Specifications

Oculus (ST)

Max Temp C°(F°): 150° (302°)
Min Temp C°(F°): -20° (-4°)
Max Duration @C: >7y @100, >5y @130, >1y @150

Oculus (HT)

Max Temp C°(F°): 177° (350°)
Min Temp C°(F°): -0° (32°)
Max Duration @C: >120d @165, >80d @177

Oculus (XT)

Max Temp C°(F°): 192° (377°)
Min Temp C°(F°): -0° (-32°)
Max Duration @C: >40d @185, >21d @192

Applications

Metrol has used OCULUS for:

  • stimulation & fracing
  • acid jobs
  • gravel packs
  • DST transient analysis
  • leak detection

Features

10k, 16k, 20k, 25k (psi)

Pressure Ranges

+/- 0.025% of Full Scale

PRESSURE Accuracy

0.0008psi (1sec sampling)

PRESSURE Resolution

Negligible

PRESSURE Drift @20°C

Benefits

4,500,000 data samples (P+T)

Memory Capacity

Dependent on Duration required

Length

1.25" (1.37" ext'd Duration)

Diameter

Progammable inhole 1/64s - 120s

sample rates

YES

Paragon enabled

DOWNLOAD OCULUS DATA SHEET
